Fav 900
Engine / Generalities
Tightening Torque values
A
General
Fav 900 from chassis number 23/3001and up
13/03/2001
2000 000007
A
a
3/4
Capitel Docu-No.
Index
Date Version
Page
Tightening Torque values
Assembly tightening torques to works standard M 3059
External or internal hexagon nuts and bolts, heads without collar or flange.
Tread size * Pitch Property class / Tightening torque in Nm (lbf-ft)
at 8,8/8 at 10,9/10 at 12,9/12
M4 2,5 (1,84) 4,0 (2,95) 4,5 (3,32)
M5 5,0 (3,69) 7,5 (5,53) 9,0 (6,64)
M6 9,0 (6,64) 13,0 (9,59) 15,0 (11,06)
M7 14,0 (10,33) 20,0 (14,75) 25,0 (18,44)
M8 22,0 (16,23) 30,0 (22,13) 35,0 (25,81)
M8*1 23,0 (16,96) 35,0 (25,81) 40,0 (29,50)
M10 45,0 (33,19) 65,0 (47,94) 75,0 (55,32)
M10*1,25 45,0 (33,19) 65,0 (47,94) 75,0 (55,32)
M10*1 50,0 (36,88) 70,0 (51,63) 85,0 (62,62)
M12 75,0 (55,32) 105,0 (77,44) 125,0 (92,20)
M12*1,5 75,0 (55,32) 110,0 (81,13) 130,0 (95,88)
M12*1,25 80,0 (59,00) 115,0 (84,20) 135,0 (99,57)
M14 115,0 (84,20) 170,0 (125,39) 200,0 (147,51)
M14*1,5 125,0 (92,20) 185,0 (136,45) 215,0 (158,58)
M16 180,0 (132,76) 260,0 (191,77) 310,0 (228,64)
M16*1,5 190,0 (140,14) 280,0 (206,52) 330,0 (243,40)
M18 260,0 (191,77) 370,0 (272,90) 430,0 (317,15)
M18*2 270,0 (199,14) 290,0 (213,89) 450,0 (331,90)
M18*1,5 290,0 (213,89) 410,0 (302,40) 480,0 (354,03)
M20 360,0 (265,52) 520,0 (383,53) 600,0 (442,54)
M20*2 380,0 (280,27) 540,0 (398,28) 630,0 (464,66)
M20*1,5 400,0 (295,02) 570,0 (420,41) 670,0 (494,17)
M22 490,0 (361,40) 700,0 (516,29) 820,0 (604,80)
M22*2 510,0 (376,16) 730,0 (538,42) 860,0 (634,30)
M22*1,5 540,0 (398,28) 770,0 (567,92) 900,0 (663,80)
M24 620,0 (457,29) 890,0 (656,43) 1040,0 (767,06)
M24*2 680,0 (501,54) 960,0 (708,06) 1130,0 (833,44)
M24*1,5 740,0 (545,8) 1030,0 (759,69) 1220,0 (899,82)
