Fav 900
Engine / Cold start booster
Removing and refitting heater plug
G
Repair
Fav 900 chassis number 23/3001 and up
08.02.2001
2180 000001
G
a
1/1
Capitel Docu-No.
Index
Date Version
Page
Removing and refitting heater plug
PM-Picturemodule
PM-Picturemodule
PM-Picturemodule
PMTAB_Picture
Remove heater plug
Disconnect the heater plug.
Unscrew threaded union of fuel line.
Release lock nut of heater plug and remove plug.
PMTAB_Picture
Refitting heater plug
Unscrew the lock nut on the heater plug as far as
possible. Wetten threads with "Curil T" sealant
Screw in heater plug to the end position of the lock
nut and align with fuel line.
Reconnect fuel line and electrical connections.
Tighten lock nut.
PMTAB_Picture
Checking solenoid valve for leaks
Remove fuel line from heater plug: Make sure
there are no fuel leaks when the engine is running
and warm.
Removing the solenoid valve
● Remove fuel line.
● Remove electrical connection from valve.
● Unscrew both screws and remove solenoid
valve
The valve cannot be repaired.
Damaged valves must be replaced.
Refitting the solenoid valve
● Fit valve bracket.
● Connect fuel lines using new seals.
● Re- connect solenoid valve.
