Fav 900
Engine / Generalities
Special tools
A
General
Fav 900 chassis number 23/3001and up
19/03/2001
9920 000004
A
a
6/7
Capitel Docu-No.
Index
Date Version
Page
Special tools
Text-module
Text-module
Note:
* MAN-tools without a Fendt-spare part number can be ordered by MAN-Service-Centres.
** Fendt-spare part number
Diagram -
Nb.
Description Reference
36 Compression recorder 80.99605-0164*
- Angle adaptor 81.98110-0099*
- Diagram discs (Packs.of 100 pieces) 80.99605-0165*
37 Mounting tube for valve rod bushings 80.99606-0287*
Press tube for valve rod bushings 80.99604-0106*
38 Press in and out device for valve guides including pressing plate for valve
seat rings
80.99604-0050*
Device consisting of:
Press mandrel for valve guides 80.99604-0051*
Pressing bush (spacer bush) 80.99604-0052*
pressing plate for inlet valve seat ring 80.99604-0114*
pressing plate for exhaust valve seat ring 80.99604-0054*
39 Mounting plate for compressor drive gear. 80.99606-0078*
necessary
4 Screws M 8*22 DIN 933 06.01304-7114*
1 Screw M 12*30 DIN 933 06.01304-7317*
Belt tension gauge (typ1; 200 - 600N) X899.980.218**
40 Belt tension gauge (typ1; 500 - 1500N) X899.980.219**
41 Guide mandrel (2 off) for fitting flywheel, see sketch for manufacturing.
42 Crankshaft actuating device. X899.980.220.0-
00**
