Festo CMSH - Page 53

Festo — CMSH — 2021-10
Commissioning
53
Value range Description
0.0 … 100.0% Permissible setting range, factory setting: 2.0%
Tab. 60: DO2 lower value
DO2 upper value
The ‘DO2 upper value’ parameter defines the upper limit value for monitoring the actual position. This
value must be reached or exceeded in order to generate feedback at digital output 2.
Value range Description
0.0 … 100.0% Permissible setting range, factory setting: 98.0%
Tab. 61: DO2 upper value
DO2 state configuration
The ‘DO2 state configuration’ parameter defines which active status group is output at digital output
2
è
Fig. 6. The allocation of the NAMUR classification can only be changed via DTM or EDD. If a value
is activated, a signal for the selected status group is output at digital output 2. Multiple selections are
possible.
Option Value
range
Description
Maintenance req. active,
inactive
Maintenance required
Factory setting: inactive
Out of spec. active,
inactive
Outside the specification
Factory setting: inactive
Check function active,
inactive
Functional check
Factory setting: inactive
Failure active,
inactive
Error
Factory setting: inactive
Tab. 62: DO2 state configuration
7.2.4.4 Device
Menu option Description
Assembly Related The assembly-related parameters can be configured in
this area.
è
‘Assembly Related’ menu
Actuator type
Actuator function
Position sensor type
Safety position
Exhaust position
