Commissioning
Menu option Description
The assembly-related parameters can be configured in
this area.
è
‘Assembly Related’ menu
Extension Modules
Display The parameters can be configured that define the proper-
ties of the display in this area.
è
‘Display’ menu
Language
Unit pressure
Unit temperature
Display Orientation
Tab. 63: Device
‘Assembly Related’ menu
Actuator type
The ‘Actuator type’ parameter defines the drive type to which the positioner is attached. Sine correc-
tion can be activated for linear drives with lever kinematics for position detection.
Value Description
rotary Factory setting
linear —
linear with lever —
Tab. 64: Actuator type
Actuator function
The ‘Actuator function’ parameter defines the function of the attached drive.
Value Description
SINGLEACTING Factory setting for CMSH-...-S-..., cannot be changed
DOUBLEACTING Factory setting for CMSH-...-D-..., cannot be changed
SINGLEACTING
DOUBLEACTING
CMSH-...-SD-... :
Both SINGLEACTING and DOUBLEACTING can be selected in this var-
iant.
Factory setting: SINGLEACTING
Tab. 65: Actuator function
Position sensor type
The ‘Position sensor type’ parameter defines the potentiometer in use.
