Pin 6 Power supply
Pin 3 RxD/TxD-P
Pin 8 RxD/TxD-N
Pin 5 DGND
Fig. 1/6: Bus termination for cable A
390
220
390
Pin 6
Pin 3
Pin 8
Pin 5
1. Installation
CP-FB13-E 9904b 1-17
