3.2 Testing the valves
WARNING
Before starting the test:
• switch off the compressed air supply
for the valves.
• save the string assignment if it has not already
been saved.
You thereby avoid:
– unintentional or dangerous movements of the actua-
tors
– the need to press the SAVE button again.
CAUTION
– This test function runs automatically within
the CP valve terminals. All the valves are
switched on/off cyclically.
– None of the programmed locking or
switching conditions will be taken into account.
During the test routine of the CP valve terminal, all the
valves will be switched on and off at 1 s intervals.
Test routine
3. Diagnosis
CP FB13-E 9904b 3-7
