Sequence of configuration entries
CAUTION
The number of inputs/ouputs must correspond to
the equipment fitted on the CP system. Additional
inputs/outputs must not be configured as later
reserves.
DP identifier
PLEASE NOTE
The DP identifier 049 or 16DX is used here for
further examples.
The configuration data must be known or determined
for each bus slave.
There are two methods of configuring the CP system:
•• standard mode
•• compact mode
The CP system automatically recognizes the mode in
which you wish to operate the CP system, due to the
DP identifier sent by the master.
WARNING
Configure a CP system only in one of these two
methods:
••
standard mode (4 x 049)
••
compact mode (sum identifiers)
Mixing the identifiers is not permitted.
2. Commissioning
2-8 CP FB13-E 9904b
