Festo Compact Performance CP-FB9-E - Structure of Station Status 2; Structure of Station Status 3

Structure of station status 2
Octet 2: Station status_2
Bit Meaning Explanation
0
Diag.Prm_Req Logic "1":
master must configure the CP system again
1
Diag.Stat_Diag Logic "1":
master must request diagnostic data, until this bit
is set at logic "0"
2
— Always logic "1" (set by CP system)
3
Diag.WD_On Logic "1": watchdog activated
4
Diag.Freeze_Mode logic "0": Freeze activated
5
Diag.Sync_Mode logic "0": Sync activated
6
— Reserved
7
Diag.Deactivated Always logic "0" (set by CP system)
Fig. 3/5: Diagnostic bits of station status_2
Structure of station status 3
Octet 3: Station status_3
Bit Meaning Explanation
0
—
Reserved
1
—
2 —
3 —
4 —
5 —
6 —
7 Diag.Ext_
Diag_Overflow
Always logic "0" (set by CP system)
Fig. 3/6: Diagnostic bits of station status_3
3. Diagnosis
CP FB13-E 9904b 3-13
