Addressing examples in standard mode
Address of the CP system: 12
String
assignment
of CP system
DP
identifier
I/O address
(IN/OUT)
String 0:
16 outputs
and
16 electrical
inputs
049 O 20.0 ... 21.7
I 20.0 ... 21.7
String 1:
not assigned 049 O 22.0 ... 23.7
I 22.0 ... 23.7
String 2:
16 outputs
and
16 electrical
inputs
049 O 24.0 ... 25.7
I 24.0 ... 25.7
String 3:
not assigned —
Address range for other
bus slaves
See also Fig. 2/11.
