The program automatically enters in this table the ident-
ifiers in standard mode.
Standard mode
If you wish to use the compact mode, proceed as fol-
lows:
Compact mode
1. Delete the identifiers of the standard mode.
2. Select the "Universal module" in directory
\PROFIBUS-DP\Additional FIELD DEVICES\VALVES\
Festo CP FB13 in the hardware catalogue and
move it to line 0 in the table of DP identifiers in the
lower half of the screen. If necessary, repeat this for
a second identifier.
3. Open the mask "Properties - DP slave" by double-
clicking the appropriate line in the configuration table
(
2
) of the DP slave and modify the starting address
of the inputs/outputs.
4. Select the identifiers as shown in the summary in
Fig. 2/5.
The input and output addresses are assigned automat-
ically by STEP7. Proceed as follows if you wish to mod-
ify this address assignment.
Modify address
Open the mask "Properties - DP slave" by double-click-
ing the appropriate line in the configuration table of the
DP slave and modify the starting address of the inputs/
outputs.
PLEASE NOTE
With the S7-400 controllers, 4 bytes of addresses
are always reserved for each DP identifier.
This concludes the station selection and configuration.
2. Commissioning
CP FB13-E 9904b 2-25
