Example 1:
Standard mode, highest occupied string = 2
String 0 = input module, output module/valve terminal
String 1 = input module, output module/valve terminal
String 2 = output module/valve terminal
DP identifier Comment
0 16DX String 0-2 bytes per input/output
1 16DX String 1-2 bytes per input/output
2 16DX String 2-2 bytes per output (inputs not used)
Example 1 - configuration
Example 2:
As example 1, but entry in compact mode
DP identifier Comment
0 019 String 0, 1-4 bytes per input
1 037 String 0, 1, 2-6 bytes per output
Example 2 - configuration
Alternative entry via "Identifier" mask
You can also enter the identifiers via a mask:
1. Click the button "Identifier..." in the mask "Configure".
2. The mask "Configure" will open.
