2.3.2 Sending parametrizing data
The parametrizing data are transferred from the DP
master to the CP system with the function
Set_Prm
.
Octet 1: Station status
Bit Meaning Explanation
0
—
Reserved
1
—
2
—
3
WD_On
Response monitoring of CP system on/off:
logic "0": off
logic "1": on
4
Freeze_Req
logic "0": Freeze mode not requested by the master
logic "1": Freeze mode not activated by the master
5
Sync_Req
logic "0": Sync mode not requested by the master
logic "1": Sync mode not activated by the master
6
Unlock_Req
Bit 7 Bit 6 Explanation
7
Lock_Req
00min T
SDR
+ CP system parameters
may be overwritten
0 1 CP system released for other
masters
1 0 CP system blocked for other
masters
1 1 CP system released for other
masters
2. Commissioning
CP FB13-E 9904b 2-33
