Octets 2 and 3: WD_Fact_1
WD_Fact_2
Bit Meaning Explanation
Range 1-255:
The response monitoring time of the
CP system is transferred with these two octets:
T
WD
[s] = 10ms * WD_Fact_1 * WD_Fact_2
Octet 4: Minimum station delay responder (min T
SDR
)
Explanation
The minimum time which the CP system
must wait before the reply telegram may be sent
to the DP master.
Octets 5 and 6: Ident_Number
Explanation
Transfer the Ident number (= FB9C) of the
CP system;
Parametrizing telegrams to the CP system are only
accepted when the transferred and the programmed
Ident numbers are identical.
Octet 7: Group_Ident
Explanation
Not supported by the CP system
Octet 8 - 32: User_Prm_Data
Explanation
Not supported by the CP system
2. Commissioning
2-34 CP FB13-E 9904b
