2.4 Type file and device master file (GSD)
The CD ROM supplied with this manual contains the
type files and the device master file (GSD) with the spe-
cific standardized device master file for the CP system.
Device master
file
Further information can be found in the file "Readme"
on the diskette.
The device master file contains a selection of identifiers
in addition to the slave-typical entries (ident number, re-
vision, etc.).
Enter the identifiers for the CP system in the following
sequence:
1. Digital inputs
2. Digital outputs
Example:
CP system with 2 valve terminals and 2 input modules.
CP system
last used string
Identifier Assigned
address range
0
1
049
049
16 inputs/outputs
32 inputs/outputs
