1.2.2 Setting the fieldbus address
PLEASE NOTE
The fieldbus addresses of the CP system cannot be
modified by the DP master. The CP system can only
be addressed by the fieldbus addresses set on the
address selector switches.
1
2
3
Address selector switch UNITS figure
Address selector switch TENS figure
Address selector switch HUNDREDS figure
Fig. 1/2: Setting the fieldbus address on the
address selector switches
6
5
2
7
8
9
0
1
3
4
6
5
2
7
8
9
0
1
3
4
1
2
3
