2.3.7 Bus parameters/reaction times
Baud rate (kBaud) max T
SDR
(T
Bit
)min T
SDR
(T
Bit
)
.. 187.5 60
11
500 100
1500 150
3000 250
6000 450
12000 800
2.3.8 Transmission times on the PROFIBUS-DP
PLEASE NOTE
••
Observe also the cycle time of your PLC and the
update time of the PROFIBUS-DP.
The delay time within the CP system depends on the
amount of data and therefore on the string assignment:
< 5 ms.
The calculation of the complete transmission time can
be found in the controller manual.
2. Commissioning
CP FB13-E 9904b 2-39
