Festo Compact Performance CP-FB9-E - Structure of Device-Related Diagnosis 1

Structure of device-related diagnosis 1
Octet 8: Device-related diagnosis 1
Bit Meaning Explanation
0
Common error
CP system
Logic "1":
error in one or several CP strings (bits 4-7)
1
Busy Bit Logic "1":
during the start-up phase: CP system not yet
ready for exchange of data
2
-- Not assigned
3
-- Not assigned
4
Common error 0 Logic "1":
error in string 0
5
Common error 1 Logic "1":
error in string 1
6
Common error 2 Logic "1":
error in string 2
7
Common error 3 Logic "1":
error in string 3
Fig. 3/10: Diagnostic bits of device-related diagnosis 1
3. Diagnosis
CP FB13-E 9904b 3-15
