Standard mode
In the standard mode configure 16 outputs and 16 in-
puts per assigned string.
DP identifier: 049 or 16DX for each assigned string.
The table below shows the possible entries for the
valve terminal in standard mode.
Last used
string number
No. of bytes
per input
Individual identifier
0 2 16DX
1 4 16DX, 16DX
2 6 16DX, 16DX, 16DX
3 8 16DX, 16DX, 16DX, 16DX
Fig. 2/3: Standard mode – possible configuration of the
inputs and outputs
The last used string is decisive for the number of I/O
addresses, even if numerically lower strings are not oc-
cupied physically (see manual "CP system, installation
and commissioning").
Example:
CP system with 3 strings, 3 input modules, 3 output
modules, highest occupied string number = 2.
DP Identifier Comment
0 16DX I module und O module of string 0
1 16DX I module und O module of string 1
2 16DX I module und O module of string 2
Fig. 2/4: Configuration in standard mode
