Addressing examples in compact mode
Address of the CP system: 12
String
assignment
of CP system
DP
identifier
I/O address
(IN/OUT)
String 0:
8 outputs 017 037
O 20.0 ... 20.7
I 20.0 ... 21.7 (unused)
String 1:
16 inputs
O 22.0 ... 23.7 (unused)
I 22.0 ... 23.7
String 2:
16 outputs
O 24.0 ... 25.7
String 3:
not assigned
Address range for other
bus slaves
See also Fig. 2/12.
