Input and output addresses
Enter the start addresses of the inputs and outputs
under I address or O address.
Example 3:
3 strings each with input modules and output modules
or valve terminals. Input addresses as from input word
42 are used.
DP identifier Comment I address O address
0 16DX P042 P042
1 16DX P044 P044
2 16DX P046 P046
Example 3 - input and output addresses
PLEASE NOTE
With a marked I/O address range, the function "Auto
address" carries out an automatic assignment of the
free addresses in the system depending on the sys-
tem limits.
This completes the configuration/address assignment
with COM PROFIBUS.
"PROFIBUS Configuration Help tool" software
In order to simplify configuration, the CD ROM contains
the "PROFIBUS Configuration Help Tool" software.
This software will enable you to ascertain the
PROFIBUS configuration in graphic form.
Further information (directories, etc.) can be found in
the file "readme" in the main directory of the CD ROM.
2. Commissioning
CP FB13-E 9904b 2-19
