Set the fieldbus address of the CP system with the two
round address selector switches and DIL switch el-
ement no. 1. The switches are numbered from 0..9. The
arrow indicates the units or tens figure of the fieldbus
address which is set.
Summary of possible fieldbus addresses
PLEASE NOTE
Fieldbus addresses may only be assigned once per
PROFIBUS-DP interface.
Observe also any restrictions concerning the
assignment of fieldbus addresses by your DP master.
Recommendation
Assign the fieldbus addresses in ascending order.
Adapt the station numbers to suit the machine structure
of your system.
Permitted fieldbus addresses 0; ... ; 125
1. Installation
1-8 CP FB13-E 9904b
