The following tables show the possible entries for the
valve terminal in compact mode.
With input modules
Last used
string no.
No. of bytes
per input
Sum identifier
(decimal)
02 01716DI
14 01932DI
26 021–
38 023–
With output modules or valve terminals
Last used
string no.
No. of bytes
per output
Sum identifier
(decimal)
02 03316DO
14 03532DO
26 037–
38 039–
Fig. 2/5: Compact mode – possible configurations of
the inputs and outputs
Example 1
CP system with 3 strings, 3 input modules and 3 output
modules; highest occupied string number = 2.
DP identifier Comment
0 021 6 bytes per input
1 037 6 bytes per output
Example 2
CP system with 3 strings, only 3 output modules, hig-
hest occupied string number = 2.
DP identifier Comment
0 037 6 bytes per output
