2. Process the mask "Properties of the "DP master"
– bus profile
– baud rate
3. In order to simplify the configuration, there are bit
map files with icons of the valve terminals on the CD
ROM.
Copy the file PBFB13CN.BMP into directory
\STEP7\S7DATA\NSBMP on your PC/programmer.
Symbols
The bit maps can be either:
•• copied manually into the above-mentioned directory
(e.g. via Windows Explorer) or
•• loaded via menu item "Extras" – "Install new GSD" –
file type "Bit map" in hardware configuration.
Further information (directories, etc.) can be found in
the file "readme" in the main directory of the CD ROM.
4. Activate the DP master in the rack.
