Parameter overview (Data_Exchange):
Octet 1:
I/O data byte_1
Bit 0: input/output x *)
Bit 1: input/output x+1
Bit 2: input/output x+2
Bit 3: input/output x+3
Bit 4: input/output x+4
Bit 5: input/output x+5
Bit 6: input/output x+6
Bit 7: input/output x+7
Octet 2:
I/O data byte_2
Bit 0: input/output x+8
Bit 1: input/output x+9
* * *
Bit 7: input/output x+15
Octet 8:
I/O data byte_8
Bit 0: input/output x+s
Bit 1: input/output x+t
Bit 2: input/output x+u
Bit 3: input/output x+v
Bit 4: input/output x+w
Bit 5: input/output x+x
Bit 6: input/output x+y
Bit 7: input/output x+z
*) x = Address offset of the master module
