Pictograms and symbols complement the danger warn-
ings and draw attention to the nature and conse-
quences of dangers.
Pictograms
The following pictograms are used:
Uncontrolled movements of loose tubing.
Unintentional movements of the connected actuators.
High electric voltage or undefined voltage states of the
electronic components which can affect connected cir-
cutis.
Electrostatically vulnerable components.
These will be damaged if you touch the contact
surfaces.
•• This mark indicates activities which can be carried
out in any order.
Text
markings
1. Figures indicate activities which must be carried out
in the numerical order of the figures.
– Hyphens indicate general items.
Contents and general safety instructions
VIII CP FB13-E 9904b
