3. Commissioning
3-14
Festo CPX-FB36-EN en 1611a English
Using participant properties
 Use the following data in the higher-order controller
(è Tab. 3/5).
Characteristic
Description
“Vendor Name” Festo Corporation
“Vendor ID” 26 = 1A
h
“Device Type” 12 = 0C
h
“Product code” (dependent on the operating mode)
– “RemoteI/O”
– “Remote controller”
14026 = 36CA
h
14027 = 36CB
h
“Major revision” 1
“Input size”/“Output size” Dependent on CPX expansion
“Assembly instance”
– “Input”
– “Output”
– “Configuration”
SINT format
101
100
102
INT format
111
110
102
“Product Name”
CPX-FB36 Remote IO
CPX-FB36 Remote controller
Extended EtherNet/IP participant properties
Min. bus cycle time (RPI) “Request Packet Interval” 1 ms
Connections
– Total of all connections
– “Exclusive owner”
– “Input only”
– “Listen only”
Max. 32
Max. 1
Max. 32
Max. 31
1)
1) Only with simultaneous connection “Exclusive Owner” or “Input only”
Tab. 3/5: Participant features
