3.3.3.1 Behaviour during export
Behaviour during export:
– The parameters of all existing valve slots are exported, as are the slots that do not have a valve
inserted at this point.
– The parameters of all five parameter sets are exported (with system, application, tuning parameters
and associated teach-in data) (
è
3.4.3.9 Parameter sets).
– All sensor parameters (
è
3.4.3.4 Sensor parameters) are exported as long as the corresponding
input module is actually available.
–
The last saved status is exported for all parameters (via the WebConfig interface or the transfer
mode
è
3.5.4.4 Saving settings as persistent data).
– All parameters for the description of user-defined peripherals are exported, if available
è
3.4.3.5
Parameters for describing user-defined position sensors,
è
3.4.3.6 Parameters for describing user-
defined flow sensors,
è
3.4.3.7 Parameters for the description of user-defined drives.
3.3.3.2 Behaviour during import
Behaviour during import:
–
Parameters and settings for which no value was exported retain their previous value for the import.
– When the parameterisation data is read in, the values are checked for permissible value ranges. If
the limits are violated, the parameter is set to the next critical limit.
When transferring a configuration file to a device with a different construction, the following must be
observed:
– Parameterisation data for valves are assigned according to their slot.
–
When transferring from a longer device variant to a shorter one, the data of the "excess" valve
slots are ignored.
– When transferring from a shorter device variant to a longer one, data cannot be written for the
additional valve slots (with a higher slot number).
–
Parameterisation data for input modules are assigned according to their input module position (1 or
2).
– As data for analogue and digital input modules are not compatible with one another, sensor
parameters can only be imported if the type of the assembled input module corresponds with
this position between the source and target device.
–
It is possible to transfer input module parameterisation data between device variants of different
lengths (for example from 4 + 2 to 8 + 2, from 8 + 2 to 4 + 2, from 4 + 2 to 2 + 1, etc.).
Source device Target device Sensor parameters are
copied for the module
Position 1 Position 2 Position 1 Position 2
analogue digital analogue digital Position 1 and 2
analogue digital analogue analogue Position 1
analogue digital digital digital Position 2
analogue digital digital analogue –
