General Sets
MENU DEFAULT VALUES DESCRIPTION
General Sets:
Language: ##
IT IT - EN - FR -
SP - DE
Setup the language of the display.
General Sets:
Mod: ###
Mxr . . . Setup of the machine model (Normal version or with dosing
system).
General Sets:
Battery: ###
GEL GEL - WET -
AGM - GE1 -
WE1
Setup of the battery type.
General Sets:
Rst.Cnthr: #
N Reset partial hourmeter (like on “working menu”).
General Sets:
Rst.Cnthr Brsh:
N Reset hourmeter of the brush motor.
General Sets:
Rst.Cnthr Vac
N Reset hourmeter of the vacuum motor.
General Sets:
Rst.Cnthr Trct:
N Reset hourmeter of the traction motor.
Brushes Sets
Parameter Default Min ÷ Max Description
Brushes Sets:
I Max: ## [Amp]
50 20 ÷ 80 Maximum current from the main card to the brush motor.
Brushes Sets:
I Nom: ## [Amp]
22 10 ÷ 40 Rated current; with T Nom manages the amperometric protection
(alarm + stop brush motor).
Brushes Sets:
T Nom: ## [s]
30 1 ÷ 60 Rated timer; with I Nom manages the amperometric protection
(alarm + stop brush motor).
Brushes Sets:
T Off: #.# [s]
0.2 0.0 ÷ 10.0 Delay of switching off of the brush motor when the safety lever is
released.
Brushes Sets:
T Reset: ## [s]
10 0 ÷ 100 Timing of reset amperometric protection (overcurrent).
Brushes Sets:
T On: #.# [s]
0.5 0.0 ÷ 5.0 Delay to switching on of the brush motor when the safety lever is
pressed.
Brushes Sets:
Eco Speed: ## [V]
17 15 ÷ 20 Value of Voltage reduction of brush motor, during ECO mode.
Pumps Sets - Parameters not managed
Vacuum Sets
Parameter Default Min ÷ Max Description
Vacuum Sets:
I Max: ## [Amp]
40 10 ÷ 50 Maximum current from the main card to the vacuum motor.
Vacuum Sets:
I Nom: ## [Amp]
18 5 ÷ 20 Rated current; with T Nom manages the amperometric protection
(alarm + stop vacuum motor).
Vacuum Sets:
T Nom: ## [s]
30 1 ÷ 100 Rated timer; with I Nom manage the amperometric protection (alarm
+ stop vacuum motor).
Vacuum Sets:
T Off: ## [s]
20 0 ÷ 30 Delay of switching OFF of the vacuum motor when the squeegee lever
is lifted.
Vacuum Sets:
T reset: ## [s]
60 0 ÷ 100 Timing of reset amperometric protection (overcurrent).
Vacuum Sets:
Eco Speed: ## [V]
17 15 ÷ 20 Value of Voltage reduction of vacuum motor, during ECO mode
