Power Supply Calculations Calculating the System Current Draw
138 MS-9600 PN 51335:E 7/9/03
Table 5.3 contains columns for calculating current draws. For each column, calculate the current
and enter the total (in amperes) in the bottom row. When finished, copy the totals from Calculation
Column 2 and Calculation Column 3 to Table 5.4 on page 139.
Table 5.3 System Current Draw Calculations
Device Type
Calculation Column 1
Primary, Non-Fire Alarm Current
(amps)
Calculation Column 2
Primary, Fire Alarm Current
(amps)
Calculation Column 3
Secondary, Non-Fire Alarm Current
(amps)
Qty X[current draw]= Total Qty X [current draw] = Total Qty X[current draw]= Total
Main Circuit Board 1 X[0.150]= 0.150 1 X[0.170]= 0.170 1 X[0.120]= 0.120
SLC-2 Expander Module [ ] X[0.085]= [ ] X[0.085]= [ ] X[0.085]=
ACM-8RF [ ] X[0.030]= [ ]
X[0.158]
1
=
[ ] X[0.030]=
ACM-16ATF
ACM-32AF
[ ] X[0.040] [ ]
X[0.056]
2
=
[ ] X[0.040]=
AEM-16ATF
AEM-32AF
[ ] X[0.002] [ ]
X[0.018]
2
=
[ ] X[0.002]=
AFM-16ATF
AFM-32AF
[ ] X[0.040] [ ]
X[0.056]
2
=
[ ] X[0.040]=
AFM-16AF [ ] X[0.025] [ ]
X[0.065]
2
=
[ ] X[0.025]=
UDACT-F
[ ]
1 max.
X[0.040] [ ]
X[0.075]
3
=
[ ] X[0.040]=
DACT-UD
[ ]
1 max.
X[0.100] [ ] X[0.132]= [ ] X[0.100]=
LDM-32F [ ] X[0.040] [ ]
X[0.056]
4
=
[ ] X[0.040]=
LDM-E32F [ ] X[0.002] [ ] X[0.018]= [ ] X[0.002]=
LCD-80F [ ] X[0.064] [ ] X[0.064]= [ ] X[0.025]=
4XTMF [ ] X[0.005]= [ ]
X[0.011]
5
=
[ ] X[0.005]=
4-wire Detector Heads [ ]
X[ ]
6
=
[ ] X[ ]= [ ] X[ ]=
Power Supervision
Relays
7
[ ] X[0.025]= [ ] X[0.025]= [ ] X[0.025]=
CP350 & CP355 [ ] X[0.00030]=
maximum alarm draw
for all devices
0.400
[ ] X[0.00030]=
SD350 & SD355 [ ] X[0.00030]= [ ] X[0.00030]=
SD350T & SD355T [ ] X[0.00030]= [ ] X[0.00030]=
AD350 & AD355 [ ] X[0.00030]= [ ] X[0.00030]=
H350 & H355 [ ] X[0.00030]= [ ] X[0.00030]=
H350R & H355R [ ] X[0.00030]= [ ] X[0.00030]=
H355HT [ ] X[0.00030]= [ ] X[0.00030]=
D350P [ ] X[0.00030]= [ ] X[0.00030]=
D350RP [ ] X[0.00030]= [ ] X[0.00030]=
B501BH & B501BHT
8
[ ] X[0.001]= [ ] X[0.001]=
B224RB Relay Base [ ] X[0.00050]= [ ] X[0.00050]=
B224BI Isolator Base [ ] X[0.00045]= [ ] X[0.00045]=
MMF-300 [ ] X[0.00040]= [ ] X[0.00040]=
MMF-300-10 [ ] X[0.00350]= [ ] X[0.00350]=
MDF-300 [ ] X[0.00075]= [ ] X[0.00075]=
MMF-301 [ ] X[0.000375]= [ ] X[0.000375]=
MMF-302 [ ] X[0.00027]= [ ] X[0.00027]=
MMF-302-6 [ ] X[0.00200]= [ ] X[0.00200]=
BG-12LX [ ] X[0.00023]= [ ] X[0.00023]=
CMF-300 [ ] X[0.00039]= [ ] X[0.00039]=
CMF-300-6 [ ] X[0.00225]= [ ] X[0.00225]=
CRF-300 [ ] X[0.00027]= [ ] X[0.00027]=
CRF-300-6 [ ] X[0.00145]= [ ] X[0.00145]=
I300 [ ] X[0.00040]= [ ] X[0.00040]=
NAC #1
9
[ ] X[ ]=
NAC #2 [ ] X[ ]=
NAC #3 [ ] X[ ]=
NAC #4 [ ] X[ ]=
Current Draw from TB3
(nonalarm
10
)
[ ]= [ ] [ ]= [ ] [ ]=
Sum each column
11
for
totals Primary Non-Alarm = Primary Alarm = Secondary Alarm =
Table Footnote
1. All eight ACM-8RF relays activated on a single module.
2. All annunciator LEDs on
3. UDACT-F actively making phone call to central station. If the normally open contact is used, current
consumption increases to 100 mA.
4. LDM-32F with LEDs on
5. If using the Reverse Polarity Alarm output, add 0.005 amps; if using the Reverse Polarity Trouble output, add
another 0.005 amps.
6. Refer to the Device Compatibility Document for standby current.
7. Must use compatible listed Power Supervision Relay.
8. Maximum alarm current for each sounder base is 0.015 amps which must be supplied by aux. 24VDC source.
9. Current limitation of Terminal TB4 circuits is 3.00 amps per NAC.
10.The total standby current must include both the resettable (TB3 Terminals 1 & 2) and nonresettable (TB3
Terminals 3 & 4, 5 & 6) power. Caution must be taken to ensure that current drawn from these outputs during
alarm does not exceed maximum ratings specified. Current limitations of TB3 circuits is 3.0 amps per output
11.Total current draw listed above cannot exceed 7.0 amps in alarm.
