Master Programming Level Programming
MS-9600 PN 51335:E 7/9/03 97
3.6.9 Option Modules
Options available for the MS-9600 include ACM Series, Graphic and LCD
annunciators, UDACT-F Digital Alarm Communicator/Transmitter, printer connection
for acquiring hardcopy printouts of panel data and PC (Personal Computer) connection
for uploading and downloading panel data.
Pressing 3 while viewing Programming Screen #3 will display the following screen:
Note that PR4800 in the display indicates that a supervised printer, configured for 4800
baud, has been previously programmed into the system.
3.6.9.1 Annunciators/UDACT
Pressing 1 while viewing the Options Screen will cause the control panel to display
the following screens:
A Terminal Mode annunciator
1
, ACS Mode annunciator and remote UDACT can be
installed in the MS-9600 system. To enable any of these devices, press the number
corresponding to the selected device shown in Annunciator Screen #1 so that Yes
appears in the display to the right of the device. Each press of the corresponding
number key will cause the display to toggle between Enabled Yes and Enabled No.
Note:
1. The LCD-80F is a Terminal Mode annunciator. To enable the MS-9600 for
LCD-80F operation, program Term Enabled to Yes.
PROGRAMMING
1=HISTORY
2=WALKTEST
3=OPTION MODULES
Programming Screen #3
OPTION MODULES
1=ANNUNCIATORS/UDACT
2=ONBOARD DACT
3=PRINTER/PC PR4800
Options Screen
ANNUNCIATORS
1=TERM ENABLED YES
2=ACS ENABLED YES
3=UDACT YES
Annunciator Screen #1
ANNUNCIATORS
1=ACS INSTALLED
2=FUTURE USE
Annunciator Screen #2
To Next Page
