3.6.2 Point Program
The Point Program option allows the programmer to add a new addressable device to an
SLC loop, delete an existing device from a loop or change the programming for an
existing device. Pressing 2, while viewing Programming Screen #1, will select the
Point Program option and display the following screen:
The programmer selects the desired SLC loop by pressing 1 or 2 in Point Program
Screen #1, which causes the panel to display the following screen:
3.6.2.1 Detector Programming
Pressing 1, while viewing Point Program Screen #2, will allow the programmer to
add, delete or change the programming of an addressable detector. The following
screen will be displayed by the control panel:
3.6.2.1.1 Add Detector
Pressing 1 while viewing the Detector Screen will display the following screen
which allows the programmer to add a new detector address to programming:
A flashing cursor will appear in the position of the first asterisk to the left. The
programmer keys in the three digit detector address, such as 005.
PROGRAMMING
1=AUTOPROGRAM
2=POINT PROGRAM
3=ZONE SETUP
Programming Screen #1
POINT PROGRAM
SELECT LOOP
1=LOOP 1
2=LOOP 2
Point Program Screen #1
POINT PROGRAM
SELECT TYPE
1=DETECTOR
2=MODULE
Point Program Screen #2
DETECTOR
1=ADD
2=DELETE
3=EDIT
Detector Screen
ADD DETECTOR
ENTER DETECTOR#
***
Add Detector Screen
