Fire-Lite MS-9600 User Manual

Master Programming Level Programming
MS-9600 PN 51335:E 7/9/03 77
3.6.3.2 Disable
Pressing 2 for Disable, while viewing Zone Setup Screen #1, will display the
following screen:
This screen allows the programmer to disable zones, one at a time. A flashing
cursor appears next to the Z, prompting the programmer to enter a two digit zone
number (01 - 99). When the second digit is entered, the zone will be disabled and
the cursor will return to the original position next to the Z. Another zone can then
be disabled.
3.6.3.3 Zone 97, 98 and 99
Pressing 3 for Zone 97, 98 and 99, while viewing Zone Setup Screen #1, will
display the following screen:
Zones 97, 98 and 99 can be programmed for normal zone operation or for special
purpose applications. In the above illustration, the three zones are shown Off,
which means they can be programmed to function in the same manner as all other
zones, by assigning them to input and output devices in the Programming Zone
Assignment Screen.
Pressing 1 will cause the display to change to PAS 97 On. Each press of the 1 key
will cause the display to toggle between PAS 97 On and PAS 97 Off. When Zone 97
is programmed On, a PAS (Positive Alarm Sequence) activation of any device will
cause Zone 97 to activate. By assigning Zone 97 to a control module in the
Programming Zone Assignment Screen, an output device connected to the control
module can be used to indicate a PAS condition in the control panel. Do not assign
Zone 97 to a Notification Appliance Circuit when using this zone to indicate a PAS
condition.
Pressing 2 will cause the display to change to Pre-signal 98 On. Each press of the 2
key will cause the display to toggle between Pre-signal 98 On and Pre-signal 98
Off. When Zone 98 is programmed On, a Pre-signal activation of any device will
cause Zone 98 to activate. By assigning Zone 98 to a control module in the
Programming Zone Assignment Screen, an output device connected to the control
module can be used to indicate a Pre-signal condition in the control panel. Do not
assign Zone 98 to a Notification Appliance Circuit when using this zone to indicate
a Pre-signal condition.
Zone 99, in special purpose mode, is reserved for future use and has no effect.
ZONE SETUP
1=ENABLE
2=DISABLE
3=ZONE 97 98 99
Zone Setup Screen #1
ZONE TO DISABLE
Z
Disable Screen
SPEC PURPOSE ZONE
1=PAS 97 OFF
2=PRESIGNAL 98 OFF
3=ZONE 99 OFF
Zone 97, 98 and 99 Screen
