Fire-Lite MS-9600 - ACM and AFM Series Annunciators

Installation Optional Modules and Devices
42 MS-9600 PN 51335:E 7/9/03
2.6.6.4 ACM and AFM Series Annunciators
ACM and AFM Series Annunciators provide visual indications of FACP status in
remote locations. Refer to the appropriate annunciator manual for information on
installation, wiring and operation.
Annunciator addressing is specific to the MS-9600 control panel. The following
table describes the annunciator addresses and the corresponding addressable
devices that will be annunciated at each annunciator address.
Important: If a UDACT-F is installed in the MS-9600 and selected in programming,
the control panel will automatically assign annunciator addresses 20 - 31 to the
UDACT-F and disable the selection of these addresses in programming for ACM
annunciators. Do not
set any ACM annunciators to these addresses.
The MS-9600 must be programmed for the annunciators installed on the system.
Refer to "Annunciators/UDACT" on page 97 for information on UDACT-F and
annunciator programming. Make certain to program the annunciator addresses that
have been physically installed on the system.
Note: The 8 General System Status Points include the following:
• General Alarm
• General Trouble
• General Supervisory
• Alarm Silenced
• System Off Normal
•AC Loss
• Battery Fault
• NAC Fault
ACM Annunciator Address Annunciator Displays the Following Points
1 8 General System Status Points & Zones 1 - 56
2 Zones 57 - 99 & 4 NACs
3 Loop 1, Module Addresses 1 - 64
4 Loop 2, Module Addresses 1 - 64
5 Loop 1, Module Addresses 65 - 128
6 Loop 2, Module Addresses 65 - 128
7 Loop 1, Module Addresses 129 - 159 & Loop 2 Module Addresses 129 - 159
8 Loop 1, Detector Addresses 1 - 64
9 Loop 2, Detector Addresses 1 - 64
10 Loop 1, Detector Addresses 65 - 128
11 Loop 2, Detector Addresses 65 - 128
12 Loop 1 Detector Addresses 129 - 159 & Loop 2 Detector Addresses 129 - 159
13 not used
14 not used
15 not used
16 not used
17 not used
18 not used
19 not used
20 8 General System Status Points & Zones 1 - 56
21 Zones 57 - 99 & 4 NACs
22 Loop 1, Module Addresses 1 - 64
23 Loop 2, Module Addresses 1 - 64
24 Loop 1, Module Addresses 65 - 128
25 Loop 2, Module Addresses 65 - 128
26 Loop 1, Module Addresses 129 - 159 & Loop 2 Module Addresses 129 - 159
27 Loop 1, Detector Addresses 1 - 64
28 Loop 2, Detector Addresses 1 - 64
29 Loop 1, Detector Addresses 65 - 128
30 Loop 2, Detector Addresses 65 - 128
31 Loop 1 Detector Addresses 129 - 159 & Loop 2 Detector Addresses 129 - 159
32 not used
