Master Programming Level Programming
MS-9600 PN 51335:E 7/9/03 95
3.6.7 History
The History option allows an authorized user to view or erase events which have
occurred in the control panel. Pressing 1 while viewing Programming Screen #3 will
display the History options as shown in the following display:
3.6.7.1 View Events
Pressing 1 while viewing the History Screen will allow the user to select the events
to be viewed as illustrated in the following:
While displaying the View Events screen, press 1 to view all events, 2 to view only
alarms or 3 to view other events. Use the up and down arrow keys to scroll through
all of the displayed events.
3.6.7.2 Erase History
The Erase History option allows a user to erase all events from the history file. This
will provide a clean slate in order to use the history file to track future events.
Pressing 2 while viewing the History Screen will cause the following screen to be
displayed:
Pressing 1 while viewing the Erase History Screen will erase all events from the
History file. During this process, the display will read as follows:
After the History file has been erased, the display will return to the History Screen.
PROGRAMMING
1=HISTORY
2=WALKTEST
3=OPTION MODULES
Programming Screen #3
HISTORY
1=VIEW EVENTS
2=ERASE HISTORY
History Screen
HISTORY
1=VIEW EVENTS
2=ERASE HISTORY
History Screen
HISTORY
1=VIEW ALL
2=VIEW ALARMS
3=VIEW OTHER EVENTS
View Events Screen
ERASE HISTORY
PROCEED ?
1=YES 2=NO
Erase History Screen
ERASING HISTORY
PLEASE WAIT
Erase History Wait Screen
