Programming Master Programming Level

52 MS-9600 PN 51335:E 7/9/03

The following examples show the editing of a photoelectric smoke detector with

address 017, located on the first SLC loop:

Enable/Disable Detector

To Enable or Disable the detector, press the 1 key while viewing the Edit Detector

Screen #2. Each press of the key will toggle the screen between Enabled Yes and

Enabled No. If Enabled No is selected, the detector will not be polled by the control

panel, preventing the detector from reporting alarms and troubles to the panel. The

control panel will display the device type and address which has been disabled and

will turn on the Trouble LED and Disable LED.

EDIT DETECTOR 1D017

1=ENABLED YES

2=TYPE SMOKE(PHOTO)

3=VERIFICATION OFF

Edit Detector Screen #2

EDIT DETECTOR 1D017

1=WALKTEST NO

2=PAS NO

3=PRE-SIGNAL NO

Edit Detector Screen #3

EDIT DETECTOR 1D017

1=ZONE ASSIGNMENT

00 ** ** ** **

Edit Detector Screen #4

Edit Detector Screen #5

EDIT DETECTOR 1D017

1=NOUN/ADJECTIVE

2=DESCRIPTION

********************

EDIT DETECTOR

1=ENABLED

2=TYPE

3=VERIFICATION

Edit Detector Screen #2
