Fire-Lite MS-9600 User Manual

Master Programming Level Programming
MS-9600 PN 51335:E 7/9/03 71
Type
To select the type of control module being programmed, press the 2 key while
viewing the Edit Control Screen #2. This will cause the control panel to display the
following Control Type Screens:
While viewing one of the Control Type screens, select the type of control module
being programmed by pressing the corresponding keypad number key. The display
will return to the Edit Control Screen #2 and indicate the new type selection.
Notes:
1. A control module set to the Resettable Power type will follow the main circuit
board 24 VDC resettable power unless the control module is disabled.
The following table contains control module type codes and their functions:
Control Type Special Function
Future Use None
Bell Circuit None
Horn Circuit None
Sounders None
Relay Ignore Open Circuit
Strobe Circuit None
Control None
Resettable Power None
Future Use None
EDIT CONTROL
1=ENABLED
2=TYPE
3=SILENCEABLE
Edit Control Screen #2
CONTROL TYPE
1=FUTURE USE
2=BELL-CIRCUIT
3=HORN-CIRCUIT
Control Type Screen #1
CONTROL TYPE
1=CONTROL
2=RESETTABLE POWER
3=FUTURE USE
Control Type Screen #3
CONTROL TYPE
1=SOUNDERS
2=RELAY-1FC
3=STROBE-CKT
Control Type Screen #2
