© 2023 Carrier 15
INSTALLATION PROCEDURE
WIRING BASE
Install the wiring base where the relative humidity never reaches the saturation point. The
Burner-Logix system is designed to operate in a maximum 90% relative humidity
continuous, non-condensing environment. Do not install the BurnerLogix system where it
can be subjected to vibration in excess of 0.5G continuous maximum vibration. The
BurnerLogix system does not use a weather tight enclosure. The standard vertical position
is recommended. Allow at least one inch clearance around the control for service and
installation.
1. Wiring must comply with all applicable codes, ordinances, and regulations.
2. Wiring must comply with NEC Class 1 (Line Voltage) wiring. (EU or Local Codes)
3. Torque rating on terminal block screws is 4.4 in/lbs. to 5.3 in/lbs.
4. Limits and interlocks must be rated to simultaneously carry and break current to the
ignition transformer, pilot valve and main fuel valve(s).
5. Recommended wire routing of lead wires:
a. Do not run high voltage ignition transformer wires in the same conduit with any
other wires.
b. Do not route flame detector lead wires in conduit with line or high voltage
circuits. Use separate conduit where necessary.
6. Maximum wire lengths:
a. The maximum lead wire length is 200 ft. (61 meters) to terminal inputs
(Operating limits, interlocks, valves, etc.).
b. Flame Detector lead wires: see section on flame scanners.
c. Remote reset: The maximum length of wire is 500 feet (152 meters) to a normally
open remote reset push-button, which must remain within sight and sound of the
burner.
d. Modbus communications: The maximum cable length of wire is 3300 feet (1000
meters) for RS-485.
A good ground system must be provided to minimize the effects of AC quality problems. A
properly designed ground system meeting all the safety requirements ensures that any AC
voltage quality problems, such as spikes, surges and impulses have a low impedance path to
ground. A low impedance path to ground ensures that large currents with any surge voltages
follow the desired path to earth ground.
BEFORE INSTALLING THE BURNERLOGIX CONTROL
WARNING: Controls require safety limits using isolated mechanical contacts.
Electronic limit switches can cause erratic operation and must be avoided.
CAUTION: Ensure that electric power is turned off. Refer to SN-100 for recommended
grounding techniques.
Power to some interlocks (operating controls, air flow switches, modulating circuits,
etc.) can be derived from sources other than what is controlling the BurnerLogix.
