–36–
Section 9. EXTERNAL SOUNDERS
This section provides a list of compatible sounders and connection information for an
external sounder.
Compatible Sounders
AB-12M 10Ó Motorized
Bell & Box
Motor bell & box. UL Grade A. 100 mA
current draw.
1011BE12M 10Ó
Motorized Bell & Box
Motor bell & box. UL Listed. 100 mA current
draw.
702 Outdoor Siren Self-contained 6Ð12 volt siren (driver built-in)
and weatherproof for outdoor use. Can be
wired for either a steady or warble sound.
719 2-Channel Siren Two-channel, self-contained 6Ð12-volt siren
(driver built in). 109dB @ 10 feet. 550mA
current draw.
747 Indoor Siren Self-contained 12 volt siren (driver built-in)
for indoor wall mount. 747F available for
flush mounting.
747UL Indoor Siren Self-contained siren (driver built-in) for indoor
wall mount. UL Listed.
744 Siren Driver 6 jumper-selected sound outputs. Rated at
119dB with use of an 8-ohm 30 watt speaker.
745X3 Voice Siren
Driver
Voice siren driver with English, Spanish and
French voice messages. Separate messages for
Fire and Burglary. Use with 8-ohm speaker.
UL Listed.
705Ð820 5-inch Round
Speaker
15-watt, 8-ohm speaker.
713 Speaker 40-watt, 8-ohm, indoor/outdoor speaker.
System Sensor PA400B
(beige)/PA400R (red)
Indoor Piezo Sounder
Indoor piezo sounder (red or beige), rated at
90 dB @ 10 feet.
U
L
Ê¥Use only UL Listed sounding devices for UL installations.
¥ The total current drawn from the alarm output and the
auxiliary power
output, combined, cannot exceed 700 mA. In addition, the sounding
device must be a UL Listed audible signal appliance rated to operate in a
10.2-13.8 VDC voltage range, and must be mounted indoors. Example:
Wheelock Signals Inc. siren model 34T-12 (provides 85dB[A] for NFPA
74 & Standard 985).
This control complies with NFPA requirements for temporal pulse
sounding of fire notification appliances.
Temporal pulse sounding for a fire alarm consists of the following:
3 pulses Ð pause Ð 3 pulses Ð pause Ð 3 pulses. . .
