–61–
Section 17. OUTPUT DEVICE PROGRAMMING
(*80 Menu Mode)
Programming Options Defined
The following will help you understand the programming of Output Devices
when using
✱
80 and
✱
81 modes. The options used to start and stop these
devices are described below, followed by the actual screen prompts and
available entries.
IMPORTANT: Relays
and output devices are not
recommended for life
safety applications.
The letter(s) in parentheses after each function described below, such as (A)
after ACTION, are those that appear in the various summary displays of
programmed data during programming.
ACTION (A) The "ACTION" of the device is how the device will respond
when it is activated by the "START" programming. There
are four different choices of actions:
¥ ACTIVATE for 2 SECONDS and then reset.
¥ ACTIVATE and REMAIN ACTIVATED until stopped by
some other event.
¥ PULSE ON and OFF until stopped by some other event.
¥ NOT USED when the device is not used.
START (STT) The "START" programming determines when and under
what conditions the device will be activated. The following
START options are available
:
Start By Event
1. Event (EV) is the condition (Alarm, Fault, Trouble) that
must occur to a zone or group of zones (zone list) in order to
activate the device. These conditions apply only when a
zone list is used. The different choices for "EVENT" are
listed below and in the ÒProgramming Output Relays &
Powerline Carrier devicesÓ section that follows.
¥ ALARM Relay activates upon any alarm in an
assigned zone in the zone list.
¥ FAULT Relay activates upon any opening or short
in an assigned zone in the zone list.
¥ TROUBLE Relay activates upon any trouble condition
in an assigned zone in the zone list.
¥ NOT USED Relay action is not dependent upon one of
the above events.
2. Zone List (ZL) is a group of zones to which the ÒEVENTÓ
applies in order to activate a particular device. Note that
there are a total of 3 output device related zone lists that
can be programmed in
✱
81 menu mode; when the selected
EVENT (Alarm, Fault or Trouble) occurs in any zone in
the selected ÒStartÓ ZONE LIST (1, 2, or 3), activation of
the selected device will START.
Start by Zone Type or System Operation
1. If a System Operation, such as ÒDISARMINGÓ or ÒANY
FIRE ALARM,Ó is to activate the device, the appropriate
choice would also be entered under the ÒZONE TYPEÓ
option. ÒZONE TYPEÓ is used independently of the
ÒEVENT/ZONE LISTÓ combination.
If a "ZONE TYPE" is chosen, any zone of that response type
going into alarm, trouble, or fault will cause the device to
activate as selected in "ACTION.Ó If the same ÒZONE
TYPEÓ is also chosen for the STOP programming, any zone
of that type that restores will de-activate the device.
