–73–
10 CONFIRMED
A022-4064 3
When the system sees activity on the appropriate input, it will beep
three times and display the confirmation message. Press [
✱
] or the
upper left-hand button of the program tool to when you are ready to
enroll the next transmitter.
At any time during this step, you may press the [
✱
] key on the keypad or
the upper left-hand button of the program tool if you are satisfied with
the serial and loop number combination that has been enrolled,
regardless of whether or not the enrolled input has been "confirmed."
This will ready the system to enroll the next transmitter.
If the incorrect transmitter has been enrolled, press the [#] key on the
keypad or the upper right-hand button of the program tool to delete the
serial number and return to the "LEARN S/N" prompt. A single long
beep will be heard from the keypad to verify pressing of the upper right-
hand button. Then, press "1" (Yes) or press the upper left-hand button of
the program tool (a single short beep will verify the system is ready for
enrolling) and re-activate the proper transmitter or transmitter loop
input.
7. The system will search for the next zone that does not have a serial
number associated with it. If one is found, the prompt in step 5,
along with the appropriate zone number, will be displayed. Follow
steps 5 and 6 for the remaining wireless zones.
When the last zone has been enrolled, the display will remain on that
zone. To exit this mode and return to data field program mode, press [✱].
When you have finished programming all zones, test each using the
system's TEST mode. Do not use the Transmitter ID Sniffer mode for
this, as it will only check for transmission of one zone on a particular
transmitter, and NOT the zones assigned to each additional loop.
