EasyGrid Use
r Guide MAN-00084 R 11.0
35
6.3
Statistic
Settings
This screen all
ows you to reset statis
tics associated to each individual channel
as desired
;
use the bottom r
ow buttons to scr
oll through all the
Channels
.
Reset
Description
Allows resetting
(zeroing) o
f a specific channel
statistics. Press on
the desired Reset icon
Reset for Channel #1
38
