EasyGrid User Guide MAN-00084 R 11.0
37
Temperature value desired to correspond to
20mA on the output terminal can be defined by
pressing on the corresponding digit. Type in a
value using the Numeric key pad.
Any negative or positive value, as long as the
resulting displayed temperature value is within
the calibration range.
Press to exit or to confirm.
NOTE: After a parameter is created or modified, remember to press the button when prompted,
before leaving the active screen so that the parameter is stored or the action executed.
Resulting value of Temperature Degrees per mA,
according to the set Min °T & Max °T.
To Next Page
