9 Measurement
FLUXUS G809 9.2 Measurement settings
99
UMFLUXUS_G809V2-2EN, 2020-06-25
Terminal assignment
The terminals for the connection of the output are displayed.
• Press ENTER.
If the transmitter possesses a switchable current output, it is displayed whether it is active or passive (here: active).
Output function test
The function of the output can now be tested.
• Connect an external measuring instrument to the terminals of the output.
• Enter a test value. It has to be within the output range.
• Press ENTER.
If the external measuring instrument displays the entered value, the output functions correctly.
• Select yes to repeat the test, no to return to the menu item SYSTEM settings.
• Press ENTER.
9.2.4 Activation of an analog output
• Select the channel for which an output is to be activated
in the program branch Output Options.
• Press ENTER.
This display will not be indicated if the transmitter has only
one measuring channel.
• Press ENTER until Current Loop is displayed. Select yes to activate the output.
• Press ENTER.
Special Funct.\SYSTEM settings\Proc. outputs\...\Active loop I1
Special Funct.\SYSTEM settings\Proc. outputs\...\Output Test I1
Special Funct.\SYSTEM settings\Proc. outputs\...\I1= 10 mA\Again?
Output Options
for Channel x
ENTER until
Current Loop
Meas.Values
Zero-Scale Val.
Full-Scale Val.
Test output
Error-val. delay
see annex A, p. 172
Notice!
An output can only be activated in the program branch
Output Options if it has previously been installed.
Output Options\for Channel A
Output Options\...\Current Loop
