FLUXUS WD100, WD200 13 Settings
66 UMFLUXUS_F5WDV1-1EN, 2016-04-08
13.2.1 Pipe Circumference
13.2.2 Measuring Point Number
This display will only be indicated if the transmitter has an RS485 interface.
13.2.3 Transducer Distance
13.2.4 Error Value Delay
The error value delay is the time after which an error value will be sent to an output if no valid measured values are avail-
able.
Select on if the pipe circumference is to be entered instead of the pipe diameter in the pro-
gram branch Parameter. Press ENTER.
If on has been selected for Pipe Circumfer., the outer pipe diameter will nevertheless
be requested in the program branch Parameter.
To select the menu item Pipe Circumfer., enter 0 (zero). Press ENTER.
The value displayed in Pipe Circumfer. is calculated on the basis of the last displayed
value of the outer pipe diameter.
example: 100 mm
.
π = 314.2 mm
Enter the pipe circumference. The limits for the pipe circumference are calculated on the
basis of the limits for the outer pipe diameter.
During the next scroll through the program branch Parameter, the outer pipe diameter
that corresponds to the entered pipe circumference will be displayed.
example: 180 mm : π = 57.3 mm
Note! The pipe circumference is only edited temporarily. When the transmitter switches back to the display
of the pipe circumference (internal recalculation), slight rounding errors may occur.
Example: entered pipe circumference: 100 mm
displayed outer pipe diameter: 31.8 mm
When the transmitter switches back to the display of the pipe circumference, 99.9 mm will be dis-
played.
Select (1234) if the measuring point is to be identified only by numbers, point and dash.
Select (↑↓←
→) if the measuring point is to be designated with ASCII characters.
recommended setting: user
• user will be selected if the measuring point is always the same.
• auto can be selected if the measuring point changes often.
In the program branch Measuring, the recommended transducer distance will be dis-
played in parentheses, followed by the entered transducer distance if the recommended
and the entered transducer distance are not identical.
During transducer positioning in the program branch Measuring
• only the entered transducer distance will be displayed if Transd. Distance = user
has been selected and the recommended and the entered transducer distances are iden-
tical
• only the recommended transducer distance will be displayed if Transd. Distance =
auto has been selected.
Select edit to enter an error value delay. Select damping if the damping factor is to be
used as the error value delay.
For further information on the behavior of missing measured values see section 15.1.2 and
15.2.
Meas.Point No.:
(1234) >(↑↓← →)<
Transd. Distance
auto >USER<
Transd. Distance?
(50.8) 50.0 mm
Error-val. delay
damping >EDIT<
