FLUXUS WD100, WD200 15 Outputs
74 UMFLUXUS_F5WDV1-1EN, 2016-04-08
15 Outputs
If the transmitter is equipped with outputs, they have to be installed and activated before they can be used:
• assign the physical quantity (source item) to be transmitted to the output and the properties of the signal
• define the behavior of the output in case no valid measured values are available
• activation of the installed output in the program branch Output Options
15.1 Installation of an Output
All outputs are installed in Special Funct.\SYSTEM settings\Proc. outputs.
The source items and their scroll lists are shown in Tab. 15.1.
Note! The configuration of an output will be stored at the end of the dialog. If the dialog is quit by pressing
key BRK, the changes will not be stored.
Select Special Funct.\SYSTEM settings\Proc. outputs. Press ENTER.
Select the output to be installed. Press ENTER.
The scroll list contains all available outputs. A tick after a list item indicates that this out-
put has already been installed.
This display will be indicated if the output has not been installed yet. Select yes.
Press ENTER.
If the output has already been installed, select no to reconfigure it or yes to uninstall the
output and to return to the previous menu item to select another output. Press ENTER.
Select the physical quantity (source item) to be transmitted from the source channel to the
output.
If a binary output is configured, only the list items Limit and Impuls will be displayed.
Tab. 15.1: Configuration of the outputs
source item list item output
Measuring value - physical quantity selected in the program branch Output Options
Quantity Q+ totalizer for the positive flow direction
Q- totalizer for the negative flow direction
Q sum of the totalizers (positive and negative flow direction)
Limit R1 limit message (alarm output R1)
R2 limit message (alarm output R2)
R3 limit message (alarm output R3)
Impuls from abs(x) pulse without sign consideration
from x > 0 pulse for positive measured values
from x < 0 pulse for negative measured values
Miscellaneous c-Medium sound speed of the fluid
Signal signal amplitude of a measuring channel
VariAmp standard deviation of the signal amplitude
Density density of the fluid
Pressure pressure of the fluid
SYSTEM settings↕
Proc. outputs
Install Output ↕
Current I1 ()
I1 Source item ↕
Measuring value
