FLUXUS WD100, WD200 14 SuperUser Mode
72 UMFLUXUS_F5WDV1-1EN, 2016-04-08
14.6 Number of Decimal Places of the Totalizers
The values of the totalizers can be displayed with up to 11 places, e.g., 74890046.03. In the SuperUser mode, it is pos-
sible to define the number of decimal places.
Select Special Funct.\SYSTEM settings\Measuring\Miscellaneous. Press ENTER until the menu item To-
tal digits is displayed.
Total digits = Automatic
The number of decimal places will be adjusted dynamically. Low values will first be displayed with 3 decimal places. With
greater values, the number of decimal places will be reduced.
Total digits = Fixed to x digit
The number of decimal points is constant. The max value of the totalizer is reduced with each additional decimal place.
For setting the behavior of the totalizers when the max. value is reached see section 11.3.1.
14.7 Manual Reset of the Totalizers
If the manual reset of the totalizers is activated, the totalizers can be reset to zero during the measurement by pressing
key C three times, even if a program code is activated.
Select Special Funct.\SYSTEM settings\Measuring\Miscellaneous. Press ENTER until the menu item 3xC
clear totals is displayed.
Select one of the following list items:
Automatic: dynamic adjustment
Fixed to x digit: x decimal places (range: 0...4)
Press ENTER.
max. value display
< 10
6
±0.00 ... ±999999.999
< 10
7
±1000000.00 ... ±9999999.99
< 10
8
±10000000.0 ... ±99999999.9
< 10
10
±1000000000 ... ±9999999999
decimal places max. value max. display
0< 10
10
±9999999999
1< 10
8
±99999999.9
2< 10
7
±9999999.99
3< 10
6
±999999.999
4< 10
5
±99999.9999
Note! The number of decimal places and the max. value defined here only affect the display of the totaliz-
ers.
Select on to activate the manual reset of the totalizers, off to deactivate it. Press ENTER.
Note! The manual reset of the totalizers is still active after the deactivation of the SuperUser mode.
