FLUXUS WD100, WD200 9 Basic Measurement
46 UMFLUXUS_F5WDV1-1EN, 2016-04-08
9.4 Input of the Measuring Point Number
This display will only be indicated if the transmitter has an RS485 interface.
If the data logger or the serial interface is activated, the measuring point number has to be entered:
9.5 Defining the Number of Sound Paths
9.6 Transducer Distance
The transducer distance is the distance between the inner edges of the transducers (see section 3.3 and )
In case of a measurement in diagonal arrangement on very small pipes, a negative transducer distance is possible.
Select program branch Measuring. Press ENTER.
If this error message is displayed, the parameters are not complete. Enter the missing pa-
rameters in the program branch Parameter.
Enter the measuring point number. Press ENTER.
If arrows are displayed in the lower line on the right, ASCII text can be entered. If no arrows
are displayed, only digits, point and hyphen can be entered.
A number of sound paths is recommended according to the connected transducers and the
entered parameters. Change the value, if necessary.
Press ENTER.
For defining the number of sound paths, see section 3.3.
A value for the transducer distance is recommended. Fix the transducers (see chapter 7).
Adjust the transducer distance.
Press ENTER.
Reflec - reflection arrangement
Diagon - diagonal arrangement
Note! The accuracy of the recommended transducer distance depends on the accuracy of the entered pipe
and fluid parameters.
par >MEA< opt sf
Measuring
par >MEA< opt sf
NO DATA!
Meas.Point No.:
xxx (↑↓← →)
A:
2 NUM
Sound Path
2NUM
Transd. Distance
54 mm Reflec
