A Menu Structure FLUXUS WD100, WD200
UMFLUXUS_F5WDV1-1EN, 2016-04-08 87
A Menu Structure
INIT-
resistant
Program Branch Parameter
main menu: selection of the program branch Parameter
input of the outer pipe diameter
input of the pipe circumference
This display will only be indicated if Special Funct.\SYSTEM set-
tings\Dialogs/Menus\Pipe Circumfer. is activated and Outer Diam-
eter = 0 has been entered.
input of the pipe wall thickness
range: depends on the connected transducers
default: 3 mm
selection of the pipe material
input of the sound speed of the pipe material
range: 600...6553.5 m/s
This display will only be indicated if Other Material has been selected.
selection whether the pipe is lined
selection of the lining material
This display will only be indicated if Lining = yes has been selected.
input of the sound speed of the lining material
range: 600...6553.5 m/s
This display will only be indicated if Other Material has been selected.
input of the liner thickness
default: 3 mm
input of the roughness of the inner pipe wall
range: 0...5 mm
default: 0.1 mm (for steel as pipe material)
input of the fluid temperature
default: 20 °C
input of the length of an extension cable
>PAR< mea opt sf
Parameter
Outer Diameter
100.0 mm
Pipe Circumfer.
314.2 mm
Wall Thickness
3.0 mm
Pipe Material ↕
Carbon Steel
c-Material
3230.0 m/s
Lining
no >YES<
Lining ↕
Bitumen
c-Material
3200.0 m/s
Liner Thickness
3.0 mm
Roughness
0.4 mm
Medium Temperat.
20.0 C
Additional cable
65.0 m
