FLUXUS WD100, WD200 A Menu Structure
88 UMFLUXUS_F5WDV1-1EN, 2016-04-08
Program Branch Measuring
main menu: selection of the program branch Measuring
input of the measuring point number
This display will only be indicated if Output Options\Store Meas.Data
and/or Serial Output are activated.
activation/deactivation of the flow profile correction
This display will only be indicated if Special Funct.\SYSTEM settings
\
Measuring\Flow Velocity = uncorr. has been selected.
input of the number of sound paths
display of the transducer distance to be adjusted between the inner edges of the
transducers
Program Branch Output Options
main menu: selection of the program branch Output Options
selection of the physical quantity
selection of the unit of measurement for the physical quantity
input of the duration over which a floating average of the measured values has
to be determined
range: 1...600 s
activation of the data logger
selection of the storage rate for storing measured values in the data logger
This display will only be indicated if Output Options\Store Meas.Data
and/or Serial Output are activated.
Current Loop
activation of a current output
This display will only be indicated if the current output has been installed in
Special Funct.\SYSTEM settings\Proc. outputs.
selection whether the sign of the measured values is to be considered for the
output
This display will only be indicated if Current Loop is activated.
input of the lowest/highest measured value to be expected for the current output
The values are assigned to the lower/upper limit of the output range.
These displays will only be indicated if Current Loop is activated.
INIT-
resistant
par >MEA< opt sf
Measuring
Meas.Point No.:
xxx (↑↓← →)
Transd. Distance
54 mm Reflex
par mea >OPT< sf
Output Options
Physic. Quant. ↕
Volume flow
Storage Rate ↕
Once per 10 sec.
Meas.Values
>ABSOLUT< sign
Full-Scale Val.
300.00 m3/h
To Next Page
